Abstract
Autonomous molecular machines capable of converting chemical energy into mechanical motion are foundational components for synthetic nanoscale systems. Inspired by biological motors, we report the construction of a tunable, RNA-fueled DNA origami engine that drives the cyclic movement of a 500 nm-diameter particle at the microscale. The engine operates via sequential RNA–DNA hybridization and enzymatic cleavage by RNase H, enabling reversible switching between folded and unfolded conformations without external intervention. By modulating RNA and enzyme concentrations and controlling temperature, we achieve tunable switching kinetics, with transition periods as short as ~10 s. Kinetic modeling reveals that the folding pathway is governed by both productive RNA binding and the enzymatic clearance of misfolded intermediates, while unfolding is primarily controlled by RNase H activity. Since the RNA fuel binds specifically to the DNA strands, each engine is addressable simply by changing the sequences. This work demonstrates a programmable, self-resetting molecular actuator and offers a blueprint for building more complex nanomechanical systems with forces and energies comparable to molecular motors.
Data availability
The data supporting the findings of the study are available in the article and its Supplementary Information. All data are available from the corresponding author upon request. Source data are provided with this paper. Source data is available for Figs. 2B–C, 3B–G, 4 and 5C in the associated source data file. Uncropped original gel images for Supplementary Figs. 3 and 4 are also included. Source data are provided with this paper.
Code availability
The code used for particle tracking is based on the publicly available Trackpy package (https://github.com/soft-matter/trackpy). The custom Python scripts developed for kinetic analysis, including double-exponential weighted fitting and model simulations, are available in a public GitHub repository (https://github.com/kw2556nyu/A_Tunable_Autonomous_RNA_Fueled_Micro_Engine_Analysis_Code.git) and archived with the permanent identifier https://doi.org/10.5281/zenodo.18173464. The analysis relies on standard open-source libraries (NumPy, SciPy, Matplotlib) as specified in the repository documentation.
References
Zhu, G. et al. Microchemomechanical devices using DNA hybridization. Proc. Natl. Acad. Sci. USA 118, e2023508118 (2021).
Rayment, I. et al. Three-dimensional structure of myosin subfragment-1: a molecular motor. Science 261, 50–58 (1993).
Noji, H., Yasuda, R., Yoshida, M. & Kinosita, K. Direct observation of the rotation of F1-ATPase. Nature 386, 299–302 (1997).
Wang, P.-L. et al. Transducing chemical energy through catalysis by an artificial molecular motor. Nature 637, 594–600 (2025).
Centola, M. et al. A rhythmically pulsing leaf-spring DNA-origami nanoengine that drives a passive follower. Nat. Nanotechnol. 19, 226–236 (2024).
Wilson, M. R. et al. An autonomous chemically fuelled small-molecule motor. Nature 534, 235–240 (2016).
Collins, B. S. L., Kistemaker, J. C. M., Otten, E. & Feringa, B. L. A chemically powered unidirectional rotary molecular motor based on a palladium redox cycle. Nat. Chem. 8, 860–866 (2016).
Vale, R. D. & Milligan, R. A. The way things move: looking under the hood of molecular motor proteins. Science 288, 88–95 (2000).
Vale, R. D. The molecular motor toolbox for intracellular transport. Cell 112, 467–480 (2003).
Mehta, A. D. et al. Myosin-V is a processive actin-based motor. Nature 400, 590–593 (1999).
Kumar, M., Jha, A. & Mishra, B. DNA-based nanostructured platforms as drug delivery systems. Chem. Bio Eng. 1, 179–198 (2024).
Zhang, L., Piranej, S., Namazi, A., Narum, S. & Salaita, K. “Turbo-charged” DNA motors with optimized sequence enable single-molecule nucleic acid sensing. Angew. Chem. Int. Ed. 63, e202316851 (2024).
Zhou, F. et al. Toward three-dimensional DNA industrial nanorobots. Sci. Robot. 8, eadf1274 (2023).
Xiong, Y. et al. Divalent multilinking bonds control growth and morphology of nanopolymers. Nano Lett. 21, 10547–10554 (2021).
Huang, Q. et al. Environmentally controlled oscillator with triplex guided displacement of DNA duplexes. Nano Lett. 23, 7593–7598 (2023).
Feng, Y. et al. Molecular pumps and motors. J. Am. Chem. Soc. 143, 5569–5591 (2021).
Wu, N. et al. Three-dimensional DNA nanomachine biosensor by integrating DNA walker and rolling machine cascade amplification for ultrasensitive detection of cancer-related gene. Anal. Chem. 92, 11111–11118 (2020).
Pumm, A.-K. et al. A DNA origami rotary ratchet motor. Nature 607, 492–498 (2022).
Liu, M. et al. A DNA tweezer-actuated enzyme nanoreactor. Nat. Commun. 4, 2127 (2013).
Lin, M. et al. A magnetically powered nanomachine with a DNA clutch. Nat. Nanotechnol. 19, 646–651 (2024).
von Delius, M., Geertsema, E. M. & Leigh, D. A. A synthetic small molecule that can walk down a track. Nat. Chem. 2, 96–101 (2010).
Kosuri, P., Altheimer, B. D., Dai, M., Yin, P. & Zhuang, X. Rotation tracking of genome-processing enzymes using DNA origami rotors. Nature 572, 136–140 (2019).
Yehl, K. et al. High-speed DNA-based rolling motors powered by RNase H. Nat. Nanotechnol. 11, 184–190 (2016).
Bazrafshan, A. et al. Tunable DNA origami motors translocate ballistically over μm distances at nm/s speeds. Angew. Chem. Int. Ed. 59, 9514–9521 (2020).
SantaLucia, J. A unified view of polymer, dumbbell, and oligonucleotide DNA nearest-neighbor thermodynamics. Proc. Natl. Acad. Sci. USA 95, 1460–1465 (1998).
Natsume, T., Ishikawa, Y., Dedachi, K., Tsukamoto, T. & Kurita, N. Hybridization energies of double strands composed of DNA, RNA, PNA and LNA. Chem. Phys. Lett. 434, 133–138 (2007).
Sugimoto, N. et al. Thermodynamic parameters to predict stability of RNA/DNA hybrid duplexes. Biochemistry 34, 11211–11216 (1995).
Mukherjee, S. & Warshel, A. Electrostatic origin of the unidirectionality of walking myosin V motors. Proc. Natl. Acad. Sci. USA 110, 17326–17331 (2013).
Chakraborti, A., Baldo, A. P., Tardiff, J. C. & Schwartz, S. D. Investigation of the recovery stroke and ATP hydrolysis and changes caused due to the cardiomyopathic point mutations in human cardiac β myosin. J. Phys. Chem. B 125, 6513–6521 (2021).
Uyeda, T. Q. P., Kron, S. J. & Spudich, J. A. Myosin step size: estimation from slow sliding movement of actin over low densities of heavy meromyosin. J. Mol. Biol. 214, 699–710 (1990).
Finer, J. T., Simmons, R. M. & Spudich, J. A. Single myosin molecule mechanics: piconewton forces and nanometre steps. Nature 368, 113–119 (1994).
Woodside, M. T. et al. Nanomechanical measurements of the sequence-dependent folding landscapes of single nucleic acid hairpins. Proc. Natl. Acad. Sci. USA 103, 6190–6195 (2006).
Zhang, C. et al. The mechanical properties of RNA-DNA hybrid duplex stretched by magnetic tweezers. Biophys. J. 116, 196–204 (2019).
Greenleaf, W. J., Frieda, K. L., Foster, D. A. N., Woodside, M. T. & Block, S. M. Direct observation of hierarchical folding in single riboswitch aptamers. Science 319, 630–633 (2008).
Wang, K. et al. Control and synchronization of rapid nanoscale DNA heat engine by local heating. Sci. Adv. 11, eadx6316 (2025).
Zhang, X. et al. A sensitive fluorometric bio-barcodes immunoassay for detection of triazophos residue in agricultural products and water samples by iterative cycles of DNA-RNA hybridization and dissociation of fluorophores by Ribonuclease H. Sci. Total Environ. 717, 137268 (2020).
Liu, Z. et al. Ultrasensitive fluorescent aptasensor for CRP detection based on the RNase H assisted DNA recycling signal amplification strategy. RSC Adv. 9, 11960–11967 (2019).
Fang, S., Lee, H. J., Wark, A. W., Kim, H. M. & Corn, R. M. Determination of ribonuclease H surface enzyme kinetics by surface plasmon resonance imaging and surface plasmon fluorescence spectroscopy. Anal. Chem. 77, 6528–6534 (2005).
Goodrich, T. T., Lee, H. J. & Corn, R. M. Enzymatically amplified surface plasmon resonance imaging method using RNase H and RNA microarrays for the ultrasensitive detection of nucleic acids. Anal. Chem. 76, 6173–6178 (2004).
Bazrafshan, A. et al. DNA gold nanoparticle motors demonstrate processive motion with bursts of speed up to 50 nm per second. ACS Nano 15, 8427–8438 (2021).
Harashima, T., Otomo, A. & Iino, R. Rational engineering of DNA-nanoparticle motor with high speed and processivity comparable to motor proteins. Nat. Commun. 16, 729 (2025).
Douglas, S. M. et al. Rapid prototyping of 3D DNA-origami shapes with caDNAno. Nucleic Acids Res. 37, 5001–5006 (2009).
Acknowledgements
This research received primary support from the U.S. Department of Energy under Award DE-SC0007991 (P.M.C., N.S., R.S., K.W.), which covered project conception, planning, and data analysis. The experimental implementations were supported by DOE Award DE-SC0020971 (K.W.). Computational modeling efforts were funded by the National Science Foundation through the NSF-BSF Organization Far From Equilibrium Program (GRANT NO 2414721) and the ISS: GOALI initiative (NSF Grant No. 11832291) (B.G., W.C.). Early-stage design efforts were supported by the Center for Bio-Inspired Energy Sciences (CBES), an Energy Frontier Research Center sponsored by the U.S. DOE Office of Science, Basic Energy Sciences (Award DE-SC0000989) (G.Z.). Additional funding was provided by the Office of Naval Research (ONR Grant N000141912596) and NSF CCF-2106790 (R.S., N.C.S.), and P.M.C. acknowledges support from the Simons Foundation (Award No. 7200138).
Author information
Authors and Affiliations
Contributions
Project conceptualization was led by P.M.C., N.C.S., R.S., and K.W. Sample fabrication and preparation were performed by K.W. Experimental procedures and data analysis were conducted by K.W., W.C., G.Z., Q.H., B.G., P.M.C., and N.C.S.; Overall project oversight and coordination were carried out by P.M.C. and N.C.S. The initial manuscript draft was prepared by P.M.C. and K.W. The revision experiments were conducted by G.Z., M.P., and L.Z.
Corresponding authors
Ethics declarations
Competing interests
The authors declare no competing interests.
Peer review
Peer review information
Nature Communications thanks Khalid Salaita, Luona Zhang, and Ryota Iino for their contribution to the peer review of this work. A peer review file is available.
Additional information
Publisher’s note Springer Nature remains neutral with regard to jurisdictional claims in published maps and institutional affiliations.
Source data
Rights and permissions
Open Access This article is licensed under a Creative Commons Attribution 4.0 International License, which permits use, sharing, adaptation, distribution and reproduction in any medium or format, as long as you give appropriate credit to the original author(s) and the source, provide a link to the Creative Commons licence, and indicate if changes were made. The images or other third party material in this article are included in the article’s Creative Commons licence, unless indicated otherwise in a credit line to the material. If material is not included in the article’s Creative Commons licence and your intended use is not permitted by statutory regulation or exceeds the permitted use, you will need to obtain permission directly from the copyright holder. To view a copy of this licence, visit http://creativecommons.org/licenses/by/4.0/.
About this article
Cite this article
Wang, K., Chen, W., Guo, B. et al. A tunable autonomous RNA-fueled micro-engine. Nat Commun (2026). https://doi.org/10.1038/s41467-026-69521-x
