Supplementary Figure 8: Retrograde tracing from putative projection targets of Rspo2+ and Ppp1r1b+ BLA neurons.
From: Antagonistic negative and positive neurons of the basolateral amygdala
smFISH of Rspo2 and Ppp1r1b in CTB injected brains. Rspo2 (a) and Ppp1r1b (b) expression in the BLA of CeC-CTB mice. Rspo2 (c) and Ppp1r1b (d) expression in the BLA of CeL/M-CTB mice. Rspo2 (e) and Ppp1r1b (f) expression in the BLA of NAc-CTB mice. Scale bar 250μm. (a) Day 1 t(14) = 0.4779, day 2 t(14) = 1.338. (b) Day 1 t(16) = 1.190, day 2 t(16) = 1.240. (c) t(18) = 0.5887.
