Fig. 6: Newborn CF pigs demonstrate mucus accumulation within the gallbladder lumen, but not in epithelium. | Laboratory Investigation

Fig. 6: Newborn CF pigs demonstrate mucus accumulation within the gallbladder lumen, but not in epithelium.

From: Early pathogenesis of cystic fibrosis gallbladder disease in a porcine model

Fig. 6: Newborn CF pigs demonstrate mucus accumulation within the gallbladder lumen, but not in epithelium.

a Mucin immunohistochemistry for non-CF and CF pig gallbladder tissue. Quantification of b MUC5AC and c MUC5B in the epithelium of newborn non-CF and CF pig gallbladders. Each symbol represents measurements from an individual animal. Bars represent mean ± SEM. Asterisk (*) indicates p < 0.05.
