Fig. 3: Histopathologic characteristics of observed brain lesions types.

From: Recombinant myelin oligodendrocyte glycoprotein quality modifies evolution of experimental autoimmune encephalitis in macaques

Fig. 3

A–D HE stains. E–H Iba-1 microglia/macrophagic marker expression. I–L CD3 expression in T lymphocytes. M–P IgG deposits. Q–T C1q complement protein expression. Note a relatively high number of infiltrating microglia/macrophages and CD3 positive lymphocytes in the confluent demyelination and perivascular infiltration lesion types and a relatively low IgG and C1q expression in these lesion types. In contrast to this, prephagocytic lesion and NAWM present an upregulation of Iba-1 intensity, no notifiable cellular infiltrate, and relatively high IgG and C1q expression. A–L 100× magnification. M–T 200× magnification.
