Extended Data Fig. 3: Expression of pMIR156A:GFP-N7 and pMIR157A:GFP-N7.
From: A robust mechanism for resetting juvenility during each generation in Arabidopsis
a, Expression of the pMIR156A:GFP-N7 reporter in cotyledon and leaves in long days. Dashed lines mark the successive rosette leaves (the 1st to 4th leaf). Scale bar, 0.5 mm. b, Expression of the pMIR156A:GFP-N7 reporter in pollen and mature ovule. Scale bar, 20 µm. c, Expression of pMIR156A:GFP-N7 in developing embryos. The embryos at different development stage were examined. Dashed lines mark the outline of embryos. Scale bar, 20 µm. d, Expression of pMIR157A:GFP-N7 in pollen, embryo (left) and seedling (right). Dashed lines mark the outline of a globular stage embryo, cotyledon and leaves. pMIR157A:GFP-N7 was not expressed in pollen and embryo, which were examined using a wide-field fluorescence microscope. Scale bars, 50 μm for pollen and embryo, and 0.5 mm for cotyledon and leaves.
