Extended Data Fig. 10: Phloem marker genes are expressed in 3papl mutant.
From: A root phloem pole cell atlas reveals common transcriptional states in protophloem-adjacent cells
a) Confocal pictures of 3 dps roots expressing reporters for pPAPL1::GFP/GUS, pPAPL2::VENUSer and pCDF2::VENUSer in Col0 background with and without sucrose. b) Confocal pictures of pMAKR5::MAKR5-3xYFP in Col0, 3papl and pear1pear2 mutants. c) Confocal pictures of pSBT4.12::YFPer in Col0 and 3papl mutant d) Confocal pictures of pAPL::3xYFP in 3papl crossed to Col0 (F1 +/−) or crossed to 3papl (F1 −/− e) Confocal pictures of pSBT4.12::YFPer in 3papl mutant in the presence and absence of sucrose f) Confocal pictures of pMAKR5::MAKR5-3xYFP in 3papl mutant in the presence and absence of sucrose. g) Confocal pictures of pAPL:3xYFP in 3papl mutant in the presence and absence of sucrose h) Confocal pictures of 3dps roots expressing pSUC2::GFP in wt and 3papl in the presence and absence of sucrose. The confocal signal was observed in the number of roots indicated in each picture.
