Extended Data Fig. 1: Basic Fuchsin staining in root endodermis of the 18 species.

From: The evolutionary innovation of root suberin lamellae contributed to the rise of seed plants

Extended Data Fig. 1: Basic Fuchsin staining in root endodermis of the 18 species.The alternative text for this image may have been generated using AI.

a, b, The positions for observing CS staining in dichotomous branching (a) and lateral branching (b) species as indicated by magenta or blue bars. c, Basic fuchsin staining pictures of endodermal cell walls at the positions as shown in (a) and (b). Species marked in magenta correspond to magenta bars in (a) and those marked in white correspond to blue bars in (b). These results were independently repeated three times. Lyj, Lycopodium japonicum; Sek, Selaginella kraussiana; Iss, Isoetes sinensis; Eqh, Equisetum hyemale; Opv, Ophioglossum vulgatum; Anf, Angiopteris fokiensis; Sac, Salvinia cucullata; Cer, Ceratopteris richardii; Nea, Nephrolepis auriculata; Pot, Polystichum tsus-simense; Adc, Adiantum capillus-veneris; Gib, Ginkgo biloba; Cyr, Cycas revoluta; Pib, Pinus bungeana; Tac, Taxus chinensis; Meg, Metasequoia glyptostroboides; Ors, Oryza sativa; Art, Arabidopsis thaliana. en, endodermis. Arrows pointed to the position of the Casparian strip. Scale bars: 10 µm.
