Extended Data Fig. 3: Fluorol yellow staining in root endodermis at fully developed of the vascular plants.
From: The evolutionary innovation of root suberin lamellae contributed to the rise of seed plants
a, b, The positions for observing CS staining in dichotomous branching (a) and lateral branching (b) species as indicated by colourful bars. c, d, FY 088 staining of roots at the positions as shown in (a) and (b). Species marked in magenta correspond to magenta bars in (a) and those marked in green and yellow species correspond to green and yellow bars respectively in (b). c, The overview FY 088 staining pictures of roots. These results were independently repeated three times. en, endodermis; Scale bars: 50 µm. d, Details of FY 088 staining pictures of the endodermal cells from three independent experiment. en, endodermis. Scale bars: 10 µm. Lyj, Lycopodium japonicum; Sek, Selaginella kraussiana; Iss, Isoetes sinensis; Eqh, Equisetum hyemale; Opv, Ophioglossum vulgatum; Anf, Angiopteris fokiensis; Sac, Salvinia cucullata; Cer, Ceratopteris richardii; Nea, Nephrolepis auriculata; Pot, Polystichum tsus-simense; Adc, Adiantum capillus-veneris; Gib, Ginkgo biloba; Cyr, Cycas revoluta; Pib, Pinus bungeana; Tac, Taxus chinensis; Meg, Metasequoia glyptostroboides; Ors, Oryza sativa; Art, Arabidopsis thaliana.
