Extended Data Fig. 10: Transient expression of CsLinker in Nicotiana benthamiana.
From: A promiscuous mechanism to phase separate eukaryotic carbon fixation in the green lineage
a, Confocal microscopy image of turboGFP-tagged CsLinker transiently expressed alone in Nicotiana. b, Image of chloroplast-targeted (fused to Arabidopsis RbcS signal peptide; SP1A) turboGFP expressed alone, demonstrating a lack of puncta. c, Images of transient co-expression of CsLinker-turboGFP and mCherry-tagged Nicotiana benthamiana RbcS. d, Image of NbRbcS-mCherry transiently expressed alone in Nicotiana chloroplasts. Scale bars in a-d = 5 μm. The results presented in panels a, b and d were from single non-repeated experiments. The results in panel c (and Fig. 5d) were from two independent experiments.
