Extended Data Fig. 3: Co-localization of SCEP3 and ZYP1 in various meiotic mutants.

From: The synaptonemal complex central element SCEP3 interlinks synapsis initiation and crossover formation in Arabidopsis thaliana

Extended Data Fig. 3

Immunolocalization of SCEP3-N, ZYP1-C and ASY1 or REC8 in spo11-2-3, mtopVIB-2, dmc1-2, asy3-1, rec8-1, pch2-1, asy1-4, msh5-2, hei10-2, zip4-2, mer3-1, and shoc1-1 pachytene(-like) nuclei. DNA stained with DAPI in gray. All experiments were repeated at least two times with similar results. Scale bar, 10 μm.
