Extended Data Table. 5: Electrical switching of edge current chirality in Device A at T = 2 K.
From: Electrical switching of the edge current chirality in quantum anomalous Hall insulators
a-c, Gate (Vg − Vg0) dependence of ρyx(0) (blue) and ρxx(0) (red) of the QAH insulator with right-handed CEC (that is the initial state) (a), after the first (b) and second (c) switches. d, μ0H dependence of ρyx (blue) and ρxx (red) at Vg = Vg0 and T = 2 K. e, f, μ0H dependence of ρyx at Vg = Vg0 and T = 2 K after the first (e) and second (f) switches, respectively. The red dashed curves correspond to the initial magnetization process after each switch.
