Extended Data Fig. 6: Example histology from lesioned mice depicting lesion of contralateral S1 only or additional damage to striatum.
From: Sensation, movement and learning in the absence of barrel cortex
a, Unlesioned example. b, c, Examples of S1-only lesions from two mice. d–f, Three examples of damage to striatum in addition to S1. Even minimal damage (arrows) to the dorsolateral striatum resulted in permanent behaviour deficits. Scale bar, 1 mm.
