Extended Data Fig. 10: Representative images of eyes transplanted with both safe-cell RPE and safe-cell ES cells, and only with safe-cell RPE cells.

a, b, Fundoscopy, optical coherence tomography and fluorescence imaging of eyes transplanted with safe-cell RPE and safe-cell ES cells (four-week GCV treatment). The absence of a mCherry signal indicates that ES cell growth has not occurred. b, Bottom, images of the green fluorescence channel are included to illustrate that the observed signal in the red fluorescence channel is actually autofluorescence. This experiment was repeated four times in four mice with similar results. c, Histological analysis of the eye presented in d. d, Fundoscopy, optical coherence tomography and fluorescence imaging of eyes transplanted with safe-cell RPE and safe-cell ES cells (PBS treatment). This experiment was repeated twice in two mice with similar results. e, f, Fundoscopy, optical coherence tomography and fluorescence imaging of eyes transplanted with safe-cell RPE and safe-cell ES cells, mCherry signal is detectable and indicates ES cell growth. GCV treatment began three weeks post-injection following an initial PBS treatment. This experiment was repeated four times in three mice with similar results. g, Fundoscopy, optical coherence tomography and fluorescence imaging of eyes receiving only safe-cell RPE cells (four-week GCV treatment). This demonstrates that GCV treatment did not affect the RPE cells. This experiment was repeated five times in three mice with similar results. h, Fundoscopy, optical coherence tomography and fluorescence imaging of eyes receiving only safe-cell RPE cells (four-week PBS treatment). This experiment was repeated six times in three mice with similar results. i, Fundoscopy, optical coherence tomography and fluorescence imaging of eyes receiving only HAMC (four-week GCV treatment). This experiment was repeated twice in one mouse with similar results.
