Extended Data Fig. 3: Histological assessments of bridges formed after neonatal spinal cord injury.
From: Microglia-organized scar-free spinal cord repair in neonatal mice
a, Higher-magnification images of sections of the spinal cord bridge area stained with antibodies against fibronectin, GFAP, P2Y12 and collagen I, or with DAPI (blue), at 3 dpi in P2 injury. Scale bar, 50 μm. b, Representative images of spinal sections of Cx3cr1GFP mice immunolabelled with caspase-3 showing cells around the lesion sites at 3 dpi in P2 injury. Scale bar, 200 μm. All experiments shown were independently repeated three times with similar results.
