Extended Data Fig. 14: Central projections of 11 individual VSN pathways.
From: A multidimensional coding architecture of the vagal interoceptive system
Representative brainstem images at indicated Bregma levels along the rostral-caudal axis containing central projections of 11 VSN pathways shown in Fig. 4b. Visceral organ, ending type, and Cre lines used (red) are indicated. Scale bar: 100 μm.
