Extended Data Fig. 6: Pre-vIRtPV neurons in the brainstem and motor cortex, and neurotransmitter characterization of pre-vIRtPV neurons.
a, Representative image of ΔG-GFP labelled pre-vIRtPV neurons in the brainstem (continued from Fig. 3c). Scale bars, 200 µm. b, Representative image of ΔG-GFP labelled pre-vIRtPV neurons in the cortex. Scale bar, 500 µm. c, Zoomed image of the boxed area in b, d, Representative 3D reconstructed image of labelled pre-vIRtPV neurons in the cortex (magenta). Shaded areas denote the primary motor (MOp) and secondary motor cortices (MOs). e, Neurotransmitter phenotype of pre-vIRtPV neurons determined by fluorescent in situ hybridization or HCR RNA-FISH.
