Extended Data Fig. 1: Analog in-memory computing chip and test platform.

(a) Packaged modules used in the experiments. (b) Micrograph of the chip at H3 metal level, showing all analog tiles and the corresponding area breakdown. (c) The test platform is based on a chip socket mounted on a custom board driven by 3 Xilinx Virtex-7 VC707 FPGAs. Power is supplied by four Keysight E36312A. The three FPGAs are connected through the board, and the overall system is controlled by an x86 machine using a PCIe connector. (d) For routing precision, end-to-end KWS, and RNNT power measurements, the chip is run without any need to send intermediate data back to an x86 machine during the experiment. KWS models are trained for chip deployment using HWA methods. For RNNT accuracy measurements, intermediate data moves between the chip and an x86 machine. To predict the RNNT performance, we assume digital circuitry would be integrated on the chip next to the ILP/OLP pair, leading to predictions that should be very close to a fully integrated chip in which both analog tiles and digital compute cores are tightly integrated²⁰.
