Extended Data Fig. 7: Cytoarchitectural criteria for defining intracranial datum marks of STAM.
From: A mouse brain stereotaxic topographic atlas with isotropic 1-μm resolution
a-h, Cytoarchitectural features of 8 intracranial datum marks displayed on coronal, sagittal, and horizontal planes. (a) ac-mid, (b) ac-right, (c) ac-left, (d) cc-anterior, (e) cc-posterior, (f) DGsg-mid, (g) DGsg-right, (h) DGsg-left. Blue dashed lines indicate the precise positions of each datum mark in the respective anatomical planes. In selected panels, white dashed lines outline relevant structural boundaries to aid identification. Scale bar in (a) applies to the images of all panels. The cytoarchitecture images of all 18 datum marks can be accessed via the link provided in the Data availability section.
