Extended Data Fig. 9: Blood lineage analysis of VavCretg/+ R26Tom/+ mice before and after Cyclophosphamide treatment.

From: Alternative platelet differentiation pathways initiated by nonhierarchically related hematopoietic stem cells

Extended Data Fig. 9: Blood lineage analysis of VavCretg/+ R26Tom/+ mice before and after Cyclophosphamide treatment.

a, Representative flow cytometry profiles (% of parent gates) of blood lineages of a 23 week old VavCretg/+ R26Tom/+ mouse before CP and on days 4 and 45 after CP. P: platelets, E: erythrocytes, M: myeloid (granulocytic) cells, B: B lymphoid cells, T: T lymphoid cells. b, VavCre-tdTomato labelling of blood lineages in 8–23 week old VavCretg/+ R26Tom/+ mice before and after CP (n = 6, same mice for all time points). Baseline on day -3 and CP injection on day 0. Lines connect the mean of each time point.
