Extended Data Fig. 7: BAcTrace expression in LHNs induces labelling in PNs.
From: BAcTrace, a tool for retrograde tracing of neuronal circuits in Drosophila
a, Expression of LHN driver lines tested. Anti-GFP immunostaining against UAS-csChrimson::mVenus in attP18. The name of each line is indicated on the top left and the cell type in each line on the top right. Images adapted from31 b, For each line animals of two ages were dissected. Several LHs were imaged (sample size: n number on top left corner of each image), registered to a template and averaged to produce the different panels. Bottom two panels on the right are a negative control made from line LH196 with one hemidriver missing. Epitopes detected by antibodies are indicated in bold in each panel. Genotypes for each panel are described in Supplementary Table 16. Scale bars (A) 30 µm and (B) 10 µm.
