Fig. 3 | Scientific Data

Fig. 3

From: Morphometrics of eight Chinese cavefish species

Fig. 3The alternative text for this image may have been generated using AI.

Reference showing the different shapes of the considered cavefish organs. Eye: Developed, Reduced, Absent. Mouth: Terminal, Subterminal, Inferior, Superior. Caudal fin: Rounded, Truncate, Emarginate, Forked, Lunate. Images for mouth and caudal fin are modified from38.
