Fig. 5 | Scientific Data

Fig. 5

From: High-density EMG, IMU, kinetic, and kinematic open-source data for comprehensive locomotion activities

Fig. 5

Joint angles and moments during level ground walking. Gait cycle duration normalized between two consecutive heel strikes of the same leg and moments normalized by the respective participant’s body weight. Tiles at the top annotate the walking condition. The sidestepping plots are for the foot that is in stance during sidestepping. The shaded area for the stand-to-walk, sit-to-stand-to-walk, and sidestepping represent the standard deviations for the data due to starting with the left or the right foot or sidestepping to the left or the right.
