From: Partial vs. Corona Discharges in XLPE-Covered Conductors: High-Resolution Antenna Dataset for ML Applications

Fig. 6The alternative text for this image may have been generated using AI.

Antenna C1—Principal-component analysis scatter plot. The first two PCs explain 57.4% of the variance (see Fig. 7). While background and corona are cleanly separated along PC1, the three PD-dominated classes overlap in a banana-shaped manifold, indicating residual redundancy that spills into higher components.
