Figure 3
From: In vivo dynamics of AAV-mediated gene delivery to sensory neurons of the trigeminal ganglia
Comparison of constitutive and neuronal-specific promoters for gene expression in trigeminal ganglia. Swiss Webster mice were inoculated by intradermal injection of the whiskerpad with PBS or 1 × 1011 vector genomes of scAAV1-CMV-GFP, scAAV1-sCMV-GFP, scAAV1-smCBA-GFP or scAAV1-hSyn-GFP. Sections from trigeminal ganglia harvested at 14 days post AAV delivery were stained for GFP by immunohistochemistry. Scale bar: left panel - 1 mm, right two panels - 100 μm.
