Figure 1

Sample and PL spectra. (a) Schematic view of the sample with silicon nanocrystals (shown by circles) and a gold grating. Silicon nanocrystals are shown by circles. (b) SEM images of structures under study. (c) Experimental PL spectra for different air slits widths. The black dashed line shows the spectrum for the uniform structure without slits.
