Figure 5
From: Hydrodynamic trapping measures the interaction between membrane-associated molecules
Image of a micropipette captured with a 20× magnification air objective. Solid lines denote the outer walls of the pipette, dashed lines denote the start of a new conical segment and the dotted lines represent the distance between the pipette tip and the conical segments.
