Figure 6
From: Efficient and Sensitive Electrically Small Rectenna for Ultra-Low Power RF Energy Harvesting
Simulated wire-SSRR RE (a) and impedance BW relative to 50 \({\rm{\Omega }}\) (b) versus design parameters d, h, g, and r: the variation of each parameter is from 90% to 110% of each initial value.
