From: Electrodeposited metal-organic framework films as self-assembled hierarchically superstructured supports for stable omniphobic surface coatings

Figure 2

Micro- and nanostructure of electrodeposited MOF films. (a–c) SEM images of electrodeposited Cu-BTC framework films showing (a,b) the top view on intergrown octahedral crystals, (c) a crystal surface at high magnification and (inset in a) a photograph of the MOF film. (d) SEM image of a Cu foil anodised in an electrolyte not containing linker molecules and (e,f) SEM images of other Cu-BTC framework films electrodeposited at room temperature showing (e) the top view on octahedral crystals and (f) a crystal edge at high magnification. The scale bars are (a) 10 µm, (b,e) 1 µm and (c,d,f) 100 nm.
