Figure 6
TEM results from AlCo0.5Cr0.5FeNi alloy annealed at 600 °C/15 h: (a) STEM image (b) SADP [001]B2 (c) SADP [001]BCC (d) DFTEM image from a B2 spot (e) HRTEM image showing B2 and BCC phases and (f) STEM-EDS map showing Ni partitioning in between these phases.
