Figure 6
From: Longitudinal monoaminergic PET imaging of chronic proteasome inhibition in minipigs
Preliminary immunohistochemistry of tyrosine hydroxylase positive fibers in the striatum (a,d) and neurons in the substantia nigra (b,e) and locus coeruleus (c,f) in a control minpig (top row) compared to a lactacystin-injected minipig (bottom row).
