Figure 4

Microscopic examination of H&E stained sections showed increasing degrees of tissue regeneration, epithelialization and maturation as wound healing progressed. Wounds receiving bioprinted autologous cells showed early epithelialization with almost complete coverage of the wound at 2 weeks. By week 4, autologous bioprinted wounds showed the formation of rete peg epithelial projections into the dermis, as well as the presence of keratinized stratified squamous epithelium. Wounds treated with bioprinted autologous cells showed early formation of a loosely organized papillary layer above a denser, thicker layer of reticular dermis. The structure of the tissue appeared mature and complete at 8 weeks with nicely woven dermal collagen and regularly distributed vasculature. Magnification 20x, Scale bars 100 µm.
