Figure 4
GISH analysis of BC4 progenies between Saccharum spp. and E. arundinaceus. E. arundinaceus chromosomes are shown in red and Saccharum spp. chromosomes are shown in blue. (A) 1625-13: 1 E.; (B) 1625-10: 2 E.; (C) 1625-19: 3 E.; (D) 1625-25: 3 E.; (E) 1625-23: 4 E.; (F) 1625-26: 5 E.; (G) 1514-8: 6 E.; (H) 1625-4: 4 E. + 1 E./S.; (I) 1625-7: 4 E. + 1 E./S.; (J) 1625-22: 4 E. + 2 E./S. Arrowheads in (H) (I) and (J) show translocated chromosomes. E. and S. indicate E. arundinaceus chromosomes and Saccharum spp. chromosomes, respectively. E./S. indicates translocation of the E. arundinaceus chromosome and Saccharum spp. chromosome. Scale bars: 5 μm.
