Figure 11

Picture a 2 μl droplet of water deposited on (a) a bare Si (100) substrate, (b) the same substrate coated with a layer of polycrystalline nanoporous GaN used to determine the static contact angle. (c) Picture used used to determine the advancing and recessing contact angles in the sample shown in (b) tilted by 90°.
