Figure 2
From: A Smartphone-based Diffusometric Immunoassay for Detecting C-Reactive Protein
(a) Schematic optical system of the high-resolution fluorescent microscope. (b) Setup of the optical system. (c) The ray tracing results compared to the achromatic lens set with simple dual convex lens. Schematics of the sensing mechanism.
