Figure 3
From: Electrochemical detection of different p53 conformations by using nanostructured surfaces
Characterization of bare and nanostructured electrodes using SEM: in detail, carbon SPEs (a), drop-casted MWCNTs on C SPEs (b), platinum SPEs (c) and electrochemically grown Pt NPTs on Pt SPEs (d).
