Figure 2 | Scientific Reports

Figure 2

From: Variations in tetrodotoxin levels in populations of Taricha granulosa are expressed in the morphology of their cutaneous glands

Figure 2The alternative text for this image may have been generated using AI.

Scanning electron microscopy of the poison glands of Taricha granulosa from LW− and SC+ populations. (a) In the LW− population, Type I cells have two types of granules, a smaller one with a dense appearance (*) and a larger one with a flocculent appearance (#). (b) In the SC+ population, Type I cells exhibit only flocculated granules. (c) In the LW− population, granules of Type II cells are spherical and show a smooth surface. (d) In the SC+ population, Type II cells are similar to those of the LW− population. Sexes of the animals: female (images a–d).
