Figure 5
From: Highly Responsive Ultraviolet Sensor Based on ZnS Quantum Dot Solid with Enhanced Photocurrent
HRTEM images of ZnS QD with graphene hybrids samples: (a) Low resolution images of graphene sheets decorated ZnS QDs (24 hrs) and (b) High resolution image clearly showing the QD lattice d spacing value of ~0.22 nm with corresponding 111 planes of cubic ZnS.
