Figure 3

From: Clustering of atomic displacement parameters in bovine trypsin reveals a distributed lattice of atoms with shared chemical properties

Figure 3

Comparison of ANISO change in individual (a) glycine (b) histidine and (c) tryptophan amino acid residues between odd and even diffraction images of the reference (blue) and terahertz irradiated (green) crystals. Each averaged difference is calculated from the differences in ANISO values. The error bars represent 95% CI of the mean.
