Figure 6 | Scientific Reports

Figure 6

From: An articulated Late Triassic (Norian) thalattosauroid from Alaska and ecomorphology and extinction of Thalattosauria

Figure 6

Dorsal region and pectoral girdle of Gunakadeit joseeae. (a) Photograph. (b) Interpretation of the holotype specimen UAMES 23258 in right lateral view. Abbreviations: cl, clavicle; cor, coracoid; dc, dorsal centrum; dia, diapophysis; dr, dorsal rib; gast, gastralia; hum, humerus; int, intermedium; icl, interclavicle; mc, metacarpal; ph, phalanx; ns, neural spine; rad, radius; sc, scapula; ul, ulna; ule, ulnare.
