Figure 4

Coating loss angle as function of Urbach energy. The circles and the squares refer to as deposited samples and samples after the heating treatment, respectively. Four different coatings are considered, the Ta₂O₅ (blue) and the Ti:Ta₂O₅ (green), the Nb₂O₅ (orange) and the Nb:TiO₂ (violet).
