Figure 7
From: Small-scale mechanical behavior of a eutectic high entropy alloy
(a) Bright-field TEM image of a deformed mixed micro-pillar showing the interface between L12 and B2 with high dislocation density in L12. The insets show the SAD patterns of the two phases along [110] zone axis; (b) higher magnification bright-field TEM image of L12/B2 boundary region showing the Cr-rich precipitates within the B2 phase, the phase boundary is indicated by a green dotted line in (a,b).
