Figure 4
From: Electroluminescence from μLED without external charge injection
Self-protection against electrical breakdown. (a) Schematic of the DIC. (b) Resistance–voltage relationship of LED. (c) Output voltage–load resistance and output current–load resistance relationships of the DIC. (d) Operation voltage–current relationship of the LED operating in DIC mode.
