Figure 5 | Scientific Reports

Figure 5

From: Large-scale microlens arrays on flexible substrate with improved numerical aperture for curved integral imaging 3D display

Figure 5

(a) Scheme of reconstruction stage of integral imaging, a microlens covered 5 × 5 pixels. (b) Design scheme of microlens’s pitch for the curved integral imaging 3D display system. (c) An elemental image array captured using computer graphics techniques. (d) The photo of constructed 31-inch integral imaging 3D display system with a floating 3D reconstruction image viewed from the normal direction. (e) A photo of 3D reconstruction image viewed from the left 45° direction. (f) A photo of 3D reconstruction image viewed from the right 45° direction.
