Figure 3
From: Species diversity of Pleosporalean taxa associated with Camellia sinensis (L.) Kuntze in Taiwan
Neoshiraia camelliae (NTUH 18-092-1, holotype). (a) Leaf lesions. (b) Conidioma on host surface. (c, d) Cultures on PDA, from above and below. (e) Conidiomata on pine needle. (f) Vertical section through conidioma. (g) Conidiomatal wall. (h, i) Conidiogenous cells and developing conidia. (j) Conidia. Scale bars: (f) = 10 μm, (g, j) = 5 μm, (h, i) = 2.5 μm.
