Figure 6 | Scientific Reports

Figure 6

From: Vitamin D supplementation effects on the clinical outcomes of patients with coronary artery disease: a systematic review and meta-analysis

Figure 6

Forest plot of randomized controlled trials showing weighted mean difference in HDL levels between the vitamin D-supplemented and placebo groups for all eligible studies. For all the inclusion studies pooled, the non-significant effect of vitamin D supplement on HDL levels was observed (P value for heterogeneity = 0.22, and χ2 = 1.51).
