Figure 3
A case of pachychoroid neovasculopathy with subretinal hemorrhage. Images from a 77-year-old man with visual impairment in the right eye. Best-corrected visual acuity was 20/200. (A) Color fundus photographs showing subretinal hemorrhage (SRH) ≥ 4 disc areas in size and no drusen. (B) Fundus autofluorescence showing retinal pigment epithelium abnormalities (arrows) apart from SRH. (C) Fluorescein angiography showing leakage suggesting occult choroidal neovascularization. (D) Indocyanine green angiography showing polypoidal lesions. (E) Enhanced-depth imaging optical coherence tomography showing dilated large choroidal vessels and massive SRH. The subfoveal choroidal thickness is 305 µm.
