Figure 7
From: Biomechanical analysis of costochondral graft fracture in temporomandibular joint replacement
Apply forces to the ribs from two directions: Parallel to the long axis to test axial force resistance (blue arrow); Parallel to the costal-cartilage junction to test shear force resistance (red arrow).
