Figure 4

TEM of ASx5L^T interacting with prey showing: (A–D) with E. coli prey; (E–H) with C. jejuni prey. (A) typical cell ASx5L^T attached to a single E. coli (EC) cell; (B) filamentous ASx5L^T attached to single EC cell; (C) filamentous ASx5L^T cells attached to multiple EC cells; (D) smaller ASx5L^T cell attached to a single E. coli (EC) cell; (E) single ASx5L^T cell attached to a C. jejuni (CJ) cell; (F) ASx5L^T attacking a C. hyointestinalis (CH) cell; (G) two ASx5L^T cells attacking a CJ cell; (H) close view of attachment point of ASx5L^T, close to apex of the CJ cell (bar 0.2 μm). Bar represents 1 μm in (A–G).
