Figure 2

Numerical simulation, fabrication, and measurement: (a) unit cell SM metamaterial, (b) 1 × 2 array SM metamaterial, (c) fabricated unit cell SM metamaterial, (d) fabricated 1 × 2 array SM metamaterial, (e) voxel human model, (f) metamaterial measurement setup of Vector Network Analyzer N5227A.
