Figure 2
From: Impaired differentiation of small airway basal stem/progenitor cells in people living with HIV
Disordered differentiation of ALI derived from PLWH SAE BC. Expression of differentiated-related genes in HIV− and PLWH SAE BC-derived ALI. (A) FOXJ1(ciliated cells); (B) DNA1 (ciliated cells); (C) MUC5B (secretory cells); (D) SCGB1A1 (club cells) and (E) TJP3 (tight junction) assessed by Taqman PCR. The data were normalized to 18s RNA. Data shown are the mean of each individual from one representative of three independent experiments performed in triplicate. Each individual of HIV− nonsmokers (C-1 to C-4) and PLWH (H-1 to H-4) was color-coded as indicated.
